ZLHV2300 High-Voltage Differential Probe

This high-voltage differential probe supports floating measurements with a maximum bandwidth of 220 MHz and multiple selectable ranges, meeting the requirements of most test systems and circuits. If offset drift occurs after long-term use, users can enable the auto-zero mode to automatically adjust the bias back to zero. The electronic soft-touch buttons provide enhanced durability.

Supports a 5 MHz bandwidth limit function, suitable for switching power supply FET switching frequency measurements and capable of filtering out high-frequency noise. Equipped with audible and visual alarms with manual mute control. Powered via USB Type-C for convenience. The standard BNC interface is compatible with oscilloscopes from any manufacturer (when the oscilloscope input impedance is 1 MΩ or 50 Ω, the attenuation factor increases accordingly).

Features automatic setting memory to prevent repeated configuration after power loss. Provides excellent common-mode noise rejection, high input impedance and low input capacitance, ensuring accurate differential voltage measurement. Widely used in the development, debugging, and maintenance of switching power supplies, inverters, variable-frequency appliances, and other power electronic equipment.
